B760M8

Intel B760/Q670 chipset Suppo朋照rt Intel 12/13Gen desktop proce道店ssor Support 2*PCIe×16 + PCIe×1 Expansi農鐘on slot 5.1 channel surroun師機d audio for option HD分身MI/DP/VGA Multi-d森校isplay TPM for option

技術規格
産品介紹
技術下載

- 商品名稱: B760M8
- 産品定位: Micro ATX
- 版型: Micro ATX
- CPU: Intel
- Intel: 台式機平台H610/B660/Q670 + RPL/ADL-S,台式機平台Z6睡服90/B760 + RPL-S/ADL-門商S
- 列表數據: Alder Lake-S 125W Raptor Lake-S 1公近25W B760/Q670 Micro A木什TX 244*244mm 4*DDR5 U-DIM習關M, Up to 128G 1*M.2 2242街紙/2280 PCIe×4 1*M.2 2242/2280 PCIe×4/SA錯也TA 4*SATA3.0
Intel B760/Q670 chipset 謝錢Support Intel 12/13Gen desktop processo員鄉r Support 2*PCIe×16 + PCI什雨e×1 Expansion slot 5.1 cha師時nnel surround audio for op了懂tion HDMI/DP/VGA Multi-display T都林PM for option

System

CPU

Alder Lake-S 125W Raptor Lak問我e-S 125W

Chipset

B760/Q670

Memory

4*DDR5 U-DIMM, Up to 128G

Storage

1*M.2 2242/2280 P新討CIe×4

1*M.2 2242/2280 PCIe&ti草林mes;4/SATA

4*SATA3.0

WiFi

M.2 2230 PCIe+USB&些資;CNVI

OS

Windows 11/ Linux

Rear I/O

Audio

1*Line-out + 1*Line-in + 1*Mic-in

USB

2*USB3.2 Gen2+2*USB3.2 Ge信海n1

Type-C

2 (DP+ USB 3.2 Gen2 X1+15W PD)(USB 3.2鄉去 Gen2X2)

HDMI

1*HDMI 2.1

DVI

1

VGA

1

mDP

1

LAN

1*RJ45 GLAN

Internal I/O

USB

2*Header(2*USB3.2睡舞 Gen1 + 2*USB2.0)

F_Panel

1

F_Audio

1

Open Chassis detection

1

FAN

1*4Pin CPU_FAN

2*4Pin SYS_FAN

COM

1

SATA

4*SATA

Buzzer

1

PWR

24+8 ATX Power

TPM CON

1*SPI TPM Connector

Expansion Slot

PCIe×16

2

PCIe×1

1

Mechanical

Power

ATX Power

Dimension

244X244mm
